Cream Tube betetzeko ontziak fabrikatzeko makinak

Hasiera / Betetzeko makinak / Krema betetzeko makina / Cream Tube betetzeko ontziak fabrikatzeko makinak

Cream Tube betetzeko ontziak fabrikatzeko makinak

Produktuaren Deskribapena:


Makina hau ekipamendu tekniko altua da eta arrakastaz garatu eta diseinatu da atzerrian teknologia aurreratuan sartu eta GMP eskakizuna integratuz. Egitura zuzena, funtzio osoa, funtzionamendu erraza, betetze zehatza, egonkorra eta zarata txikia ditu. PLC kontroladorearekin hartzen du. Likidoa edo abiadura handiko materialen betegarritik automatikoki funtzionatzen du lote kopuru inprimaketa arte (barne fabrikazio data), ekipamendu aproposa da ALU hodi, plastikozko hodi eta hodi anitz betetzeko eta zigilatzeko kosmetikan, farmazian, elikagaietan, itsasgarrietan eta abar. industriak, BPGren araua betetzen dute.
Cream Tube betetzeko ontziak fabrikatzeko makinak

Ezaugarriak:


1. Goi mailako funtzionamendurako pantaila LCD pantailako PLC eta botoiekin, funtzionamendu erraza eta humanizazio gehiago Pausoen abiadura doitzeko, parametroen multzoa, out zenbaketa, presio indizea eta porrotaren bistaratzea.
2. Hodi hornikuntza automatikoki exekutatzea, fotoelektroen erregistroa, gas inerteen betetzea (aukerakoa), materiala betetzea eta zigilatzea, sorta kopurua inprimatzea, azken produktuen irteera.
3. Zehaztasun handiko fotoelektroen erregistroak aberazio kromatikoko irismena murriztu zuen.
4. Doikuntzako piezak kanpoko posizioan, pantaila digitalean, doikuntza eroso eta zehatza (askotariko produktuak ekoizteko egokia).
5. Kontrol integratzaile mekanikoa, fotoelektroa, elektrikoa eta pneumatikoa, ez da inolako betetze funtziorik lortzen; Hodi akatsaren posizioa edo presioa oso baxua den zain, gelditzeko makina automatikoa babes-atea irekitzen bada.
Cream Tube betetzeko ontziak fabrikatzeko makinak

ModelGF-400 AGF-400 B
Hodi materialaHodi metalikoa, ALU hodiaPlastikozko hodia, hodi konposatua
Hodiaren diametroa10-42 mm10-60 mm
Hodi luzera50-250 (pertsonalizagarria)50-250 (pertsonalizagarria)
Betetze-bolumena5-500ml / adar (Doi)5-800ml / adar (Doi)
Betetze zehaztasuna≤ ± 1%≤ ± 1%
Abiadura3-10 r / min2,5-7 r / min
Produktuaren ahalmena30-60 Pc / min30-60 Pc / min
Aire Hornidura0.55-0.65mpa0.55-0.65mpa
Motor-potentzia2kw (380V / 220V 50Hz)2kw (380V / 220V 50Hz)
Beroa zigilatzeko potentzia3kw3kw
Dimentsio orokorra2620 × 1020 × 1980 mm2620 × 1020 × 1980 mm
Makinaren pisua1100 kg1100 kg

Oinarrizko informazioa


Aplikazioa: Itsatsi
Espezieak eratzea: botila eratzea
Gidatutako Mota: Elektrikoa
Packaging: Soft Tube
Motor-potentzia: 2kw (380V / 220V 50Hz)
Neurketa orokorra: 2620 × 1020 × 1980mm
Marka komertziala: VKPAK
Jatorria: Shanghai, Txina
Kalifikazio automatikoa: automatikoa
Mota: Betetzeko eta zigilatzeko makina
Eraketa funtzioa: betetzea
Material mota: Itsatsi
Produktuaren edukiera: 30-60 PC / Min
Bero zigilatzeko potentzia: 3kw
Makinaren pisua: 1100kg
Zehaztapena: CE


A cream tube filling packing machine is a type of packaging machinery designed for filling and packaging various types of creams, gels, pastes, and other similar products into tubes. This type of machine typically consists of several components, including a tube feeder, filling unit, sealing unit, and cutting unit. The overall production process is automated, which ensures the accuracy and consistency of the fill, as well as the speed of production.

The specific features and specifications of a cream tube filling packing machine may vary depending on the manufacturer and the intended application, but some common features include:

High precision: The filling system is designed to be accurate, with the ability to fill the exact amount of product specified, with minimal waste.

Versatility: The machine can be used for filling and packaging a wide range of products, including creams, gels, pastes, and other similar products.

Hygiene: The machine is designed to meet hygiene standards, with components made from food-grade stainless steel and other non-corrosive materials. The filling system is also designed to prevent contamination, ensuring the safety and quality of the product.

Easy to operate: The machine is typically user-friendly, with intuitive controls and easy to follow instructions. The system is also designed to be easy to maintain, with minimal downtime required for cleaning and servicing.

High production rates: A cream tube filling packing machine is designed to work at high production rates, with the capability of filling and packaging hundreds or even thousands of tubes per hour.

Overall, a cream tube filling packing machine is an efficient and reliable solution for filling and packaging various types of creams and gels into tubes. It is a popular choice for manufacturers who need to package products for retail or commercial use, with the ability to meet high standards of accuracy, consistency, and hygiene.
